Mô tả
Thông số kỹ thuật
| Outdoor Doorbell | – Image Sensor: 1/2.7 inch Progressive Scan CMOS (Supports low light sensitivity) – Lens: 2.0 mm @ F2.2,viewing angle: 162° (Diagonal) – Day & Night: IR-cut filter with auto-switching, 850 nm infrared light × 2 (max. 6m) – Max. Resolution: 2048 × 1296 – DNR: 2D/3D DNR – Video Compression: H.265 / H.264 – Frame Rate: Max: 15fps; Self-Adaptive during network transmission |
| Connection and Function | – Connection Method: Wired connection (2-Wired, capable with 4-Wired), digital signal transmission – Transmission Distance: Φ 2 x 0.75mm², max. 50m Φ 2 x 1.5mm², max. 100m Twisted pair, max. 120m – Open the door (Gate): Support 2 wiring ports. 1-10m distance. The intercom panel provides a “dry”-contact connection, without an electric current, to connect to the button for automated gate, gate breaking capacity: 12V / 2A – Unlock (Electric strike plate): Support 2 wiring ports. 1-10m distance. The electric strike plate or lock that you order must have a mechanical memory; the power supply to the electric strike plate or lock must not exceed 12V / 1.1A, otherwise should do as user manual. – Door Open Methods: 1.RFID badge unlock (Badges × 3 pcs) 2.App remote unlock 3.Indoor display unlock |
| Outdoor Doorbell Interface | – Audio Input: Built-in high-sensitivity microphone – Audio Output: Built-in high-power speaker – Doorbell Button: Yes. The light can be set on or off. – Name Card: Three handwritten name cards in total (one already on the intercom panel). The light can be set on or off. – Terminal: Two wiring ports to connect screen. Two wiring ports to connect gate. Two wiring ports to connect electric strike plate. |
| Functions | – Intelligent Alarm: Smart human motion detection, Lingering Detection – Tamper Alarm: Supports – Video Intercom: Long-distance video two-way talk |
| General | – Operation Conditions: -30°C to 60°C , Humidity 95% or less (non-condensing) – IP Grade: Waterproof, with shield cover – Size: 161 × 87 × 20 mm |
